How to Know if Your SPE/PEM Cell Is Failing — 6 Signs

An end-of-life or faulty SPE/PEM cell does not suddenly shut down – it declines. The 6 signs we identify at the Lyon 7th workshop allow us to diagnose 95% of failures in less than 2 minutes, without disassembly. This guide provides the exact checklist we use for all after-sales returns. Before thinking "warranty," check these 6 points: 70% of the time, it's a usage problem that can be corrected in 5 minutes.

Prerequisites

• Equipment: ELITE 9K + DPD kit included + microfiber cloth.
• Time: 10 minutes for complete diagnosis.
• Level: all users.

1. Step-by-step method — The 6 signs of failure

Sign n°1 — Repeated DPD test < 6,000 PPB

If 3 consecutive DPD tests (24 h apart) show pale pink or yellow instead of purple, your cell is producing less H₂. Possible causes: limescale (fixable), low battery (rechargeable), tired membrane (after-sales service).

Sign n°2 — 7 min cycle spontaneously interrupted

Blue LED turns off before the end of the cycle = thermal protection or cell undervoltage. If recurring after a full recharge: internal component. Mandatory after-sales service under warranty.

Sign n°3 — Visible bubbles diminished or absent

During a normal cycle, you should see a veil of micro-bubbles around the platinum electrode. If you no longer see anything: clogged electrode (descaling) or detached (after-sales service).

Sign n°4 — Persistent metallic or chemical odor

Beyond the first 3 break-in cycles, any metallic odor = electrode corrosion. A healthy cell produces water that is completely neutral in taste and odor. Odor = immediate after-sales service.

Sign n°5 — Abnormal heating of the base

Warm base at the end of the cycle = normal. Burning base > 50 °C or hot after 2 min = internal short circuit or faulty battery. Stop immediately, unplug, contact the workshop.

Sign n°6 — Collapsed battery life

If you charge every 2-3 cycles instead of 12-15: battery at end of life (normal at 800+ cycles) or cell consuming excessively (abnormal < 200 cycles). Free after-sales service under 5-year warranty.

2. Frequent errors

Error n°1 — Concluding "failure" without prior descaling. 60% of reported cases are due to limescale. Perform a gentle descaling (8° vinegar, 15 min) before any after-sales service.

Error n°2 — Disassembling the base to "check." IP67 seal lost, warranty voided. Any internal failure is diagnosed by DPD + LED. No need to open.

Error n°3 — Trying to repair with strong acidic products. Hydrochloric acid, drain cleaner = PEM membrane destruction in 30 sec. Only 8° white vinegar and food-grade citric acid are safe.

Error n°4 — Continuing to use a faulty cell. A corroded cell can release metallic micro-particles into the water. Stop use as soon as sign n°4 or n°5 appears.

Error n°5 — Waiting until the end of the warranty to report. 5-year parts and labor warranty. Report any symptoms within 30 days = free diagnosis. Delay > 30 days may complicate RMA.

3. FAQ — Your 5 frequent questions

Q1. How long does an SPE/PEM cell last?
5 years minimum with normal use (2-3 cycles/day with filtered water). Our Lyon 7th workshop cells last 7-8 years on average with rigorous maintenance.

Q2. What is the cost of an out-of-warranty cell replacement?
€180 for parts and labor. But 92% of our cells exceed the 5-year warranty, so it's rare.

Q3. How long does the Lyon 7th workshop after-sales service take?
Diagnosis 48-72 h after receipt, repair 5-7 days, return 6-10 days. Total 2-3 weeks max.

Q4. Can I get a replacement bottle during the after-sales service?
Upon request, loan of an ELITE 9K during repair (€50 deposit, refunded upon return).

Q5. What to do if the cell leaks?
Very rare (IP67 certified). Stop immediately, return to the workshop within 7 days. Free full replacement if manufacturing defect.

Switch to the ELITE 9K — 5-year guaranteed SPE/PEM cell

The ELITE 9K HYDROGENYX integrates a platinum-titanium SPE/PEM cell manufactured in Lyon, with a 5-year parts and labor warranty. 9,000 PPB of molecular hydrogen DPD-validated at each 7 min cycle, Lyon 7th workshop after-sales service, 60-day satisfaction guarantee. Free delivery in France within 6-10 days.
